Instantel micromate price upgrade#
An optional upgrade increases the memory to 60 MB for a storage capacity of over 4000 events. Memory: The micromate has an internal, non-volatile memory of 15 MB that can store up to 1000 events of 1-second duration. Record Modes: The Micromate supports Waveform, Waveform Manual, Histogram and Histogram Combo record modes and provides a summary in a detailed monitor log.įull Waveform Event Analysis: The Micromate includes the time of the event, trigger source, peak particle velocity (PPV) for each vibration channel, peak air overpressure, zero crossing (ZC) frequencies, peak vector sum (PVS), maximum acceleration, maximum displacement and more, all available on the unit in the field. Variable Sample Rates: 1024, 2048, and 4096 samples per second (S/s) for each channel, all with zero dead time between events.
Each Micromate is calibrated with a dedicated geophone and configured to meet the International Society of Explosives Engineers (ISEE-2017) standard. An optional additional battery pack increases monitoring time to 15 days.įeatures include USB 2.0 with Host and Device support USB support for memory sticks, Instantel compatible printer and modem user Interface: touch screen (icon-based), keypad, touch screen keyboard support of Instantel’s Auto Call Home for remote automated data reporting/transmission size small enough to be hand-held rugged and reliable design optional protective boot and faceplate storage capacity for 1,000 events (additional capacity optional) optional printer for immediate in-field printing of reports and 10 day battery life as standard with 15 days optional.Sensor Compatibility: The Micromate comes with three channels for a triaxial geophone and one channel for an air overpressure or sound level microphone. A standard lithium ion rechargeable battery pack supports 10 days of typical monitoring. An optional protective “boot” complete with faceplate provides the highest level of durability and ruggedness available in Instantel’s product line. The custom-moulded housings for the geophone and base unit are made of superior impact polycarbonate.
The base unit housing and connectors provide a water resistant seal. The base unit comes with a fully sealed top panel, non-corrosive industrial grade connectors and fully sealed electronics. Data retrieval can be as simple as copying events to an external USB memory stick (no laptop or computer is required). Data can be transferred for off unit storage or off-unit data manipulation to a computer or laptop via the convenient USB interface or via use of a compatible modem. Events and unit settings are saved in a reliable on-board, non-volatile memory with ample storage capacity for most applications and up to 1,000 events (with additional optional memory capacity available). Connectors are colour coded for easy identification and installation.
Instantel micromate price full#
A full display touch screen keyboard makes entry of data and notes convenient and easy, while the unit can also be interfaced to a laptop or computer.
Whether the user prefers touch screens, key pads, or a combination of both, the Micromate i is intuitive to use and easy to learn. With the use of a colour touch screen and icon-based user interface, Instantel claims to have set “a new industry standard for efficiency and ease of use.” A key pad compliments the user interface. Micromate also supports Instantel’s AutoCall Home™ feature when an event occurs the event is immediately captured and is automatically transmitted to the user computer – there is no need to prompt the unit to transmit data. Supported peripherals are automatically identified when connected, and associated commands and functions are made available in much the same manner as with laptop and computers. External memory sticks, and Instantel compatible printer, modem and a host of USB peripherals are supported. With so many features at such a reasonable price, the Micromate redefines industry standards for value.” Micromate supports USB 2.0 on both the host and device ports, operating up to 12 MB/sec. “Ideal for any budget, Micromate provides reliable regulatory compliance monitoring with an ISEE or DIN Triaxial geophone and ISEE Linear Microphone. Micromate™ is Instantel’s latest and it claims most cost-effective vibration monitoring solution to date for blasting in the mining industry.
